Model

HTCPD10

HTCPD15

HTCPD20

HTCPD25

Walking motor

7.5kw

7.5kw

11kw

11kw

Lifting motor

5.5kw

7.5kw

7.5w

11w

Lifting height

3m (customizable)

3m (customizable)

3m (customizable)

3m (customizable)

Rated loading weight

1000kg

1500kg

2000kg

2500kg

Machine weight

1800kg

2300kg

2800kg

3200kg

Working time

5-6hours

5-6hours

6-8hours

5-8hours

Battery type

60V73ah Tianneng Brand

60V85ah Tianneng Brand

60V200ah Tianneng Brand

60V240ah Tianneng Brand

Charging time

4-6hours

4-6hours

5-6hours

5-6hours

Charging voltage

220v(customizable)

220v(customizable)

220v(customizable)

220v(customizable)

Output voltage

60v

60v

60v

60v

Front and rear tires

front 500-8/ rear

front 650-10/ rear

front 650-10/ rear

front 650-10/ rear

400-8 solid tires

500-8 solid tires

500-8 solid tires

500-8 solid tires

Fork length

1070/1220mm

1070/1220mm

1070/1220mm

1070/1220mm

(customizable)

(customizable)

(customizable)

(customizable)

Min. ground clearance

100mm

100mm

100mm

100mm

Overall size (excluding fork length)

1800×1150×2150mm

2200*1150*2150mm

2450*1150*2150mm

2550*1150*2150mm
