Engine Model

Briggs & Stratton Engine Pioneer

Engine Type

Single cylinder, OHV, 4-stroke, air cooling

displacement

203CC

Rated Power

6.5HP/3600rpm

Fuel Type

92 # Gasoline

Fuel Tank capacity

3.6 L

Weight

Total Weight

550 kg

Maximum load

500 kg

Machin size（Without pedal, without bucket）

1570*880*1450

Bucket size with foot pedal:

2050*880*1450

Container size：

1050*730*730

Chassis width：

700

Lift data

Maximum rise

1020mm

Tipping height

970mm

Tipping interval

220mm

Track data

track width：

180

Track grounding length：

1000

Chassis ground clearance:

110

Hopper

Cargo box Capacity

200

Tipping Systme

Hydraulic Tipper

Tilting Angle

100

walk

Walking Speed

2.88

Minimum Turning radius

1150

Track gauge

520

Climbing abillty

20
