Machine weight

830kg

Number of valves

3

Load weight (kg)

200kg

Bucket capacity

0.15 m3

Max lifting power

380kg（10 cm from the ground）

Standard Tires

18*8.5-8

Engine

Briggs & Stratton/Euro 5 3864/18.2kw/23HP

(Optional HONDA HGX690 16.5kw/22.1HP)

Speed

Max. 5.5km/h

Hydraulic pressure

17Mpa

Pump flow rate

Big flow 55L/min

Cycle time

Raise :4.27s, Dump:1.34s , Lower 3.31s

Number of pumps

3

Main Valve

Itlay Brand
